Product Summary

The DA28F320J5-120 is an Intel StrataFlash memory. It contains high-density memories organized as 8 Mbytes or 4 Mwords (64-Mbit) and 4 Mbytes or 2 Mwords (32-Mbit). The DA28F320J5-120 can be accessed as 8- or 16-bit words.

Parametrics

DA28F320J5-120 absolute maximum ratings: (1)Commercial Operating Temperature: 0 to +70℃; (2)Temperature under Bias:–10 to +80℃; (3)Storage Temperature: –65 to +125℃; (4)Voltage On Any Pin (except RP#): –2.0 V to +7.0 V; (5)Output Short Circuit Current: 100 mA.

Features

DA28F320J5-120 features: (1)High-Density Symmetrically-Blocked Architecture; (2)5 V VCC Operation, 2.7 V I/O Capable; (3)Configurable ×8 or ×16 I/O; (4)120 ns Read Access Time; (5)Enhanced Data Protection Features Absolute Protection with VPEN = GND Flexible Block Locking Block Erase/Program Lockout during Power Transitions; (6)Industry-Standard Packaging μBGA Package, SSOP and TSOP Packages (32 M); (7)Cross-Compatible Command Support Intel Basic Command Set Common Flash Interface Scaleable Command Set; (8)32-Byte Write Buffer, 6 μs per Byte Effective Programming Time; (9)640,000 Total Erase Cycles (64 M) 320,000 Total Erase Cycles (32 M) 10,000 Erase Cycles per Block; (10)Automation Suspend Options, Block Erase Suspend to Read Block Erase Suspend to Program; (11)System Performance Enhancements STS Status Output; (12)Intel StrataFlash Memory Flash Technology.

Diagrams

DA28F320J5-120 block diagram
