AD8600APZ-REEL, 8-Bit Multiplying DAC, PLCC 44, 7V, 35mA, Analog Devices

Rated 5 Rating 5 | reviews | Write a review

Price:: US $6.50~7.20 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $6.50~7.20

PartNumber:: AD8600APZ-REEL

Brand:: Analog Devices - ADI | Pack: PLCC | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. James's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-03-30

From Other Seller

Part Number:AD8600APZ-REEL
US $6.50 - 7.20
2DI75D-050A

US $16.00 - 30.00 / Piece
(0) Remove
2DI240A-055

US $70.00 - 100.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The AD8600APZ-REEL is a 8-Bit Multiplying DAC. The AD8600APZ-REEL contains 16 independent voltage output digital-to-analog converters that share a common external reference input voltage. Each DAC has its own DAC register and input register to allow double buffering. An 8-bit parallel data input, four ad-dress pins, a CSselect, a LD, EN, R/W, and RSprovide the digital interface. The applications of the AD8600APZ-REEL include Phased Array Ultrasound & Sonar, Power Level Setting, Receiver Gain Setting, Automatic Test Equipment, LCD Clock Level Setting.

Parametrics

AD8600APZ-REEL absolute maximum ratings: (1)VDD1(Digital Supply) to GND: -0.3 V to +7 V; (2)VDD2(DAC Buffer/Driver Supply): -0.3 V to +7 V; (3)VCC(Analog Supply) to GND: -0.3 V to +7 V; (4)VEE(Analog Supply) to GND: +0.3 V to -7 V; (5)VREF to GND: -0.3 V to VCC +0.3 V; (6)VDD2to VREF: -0.3 V; (7)VOUTto GND: VCC; (8)Short Circuit Duration VOUTto GND or Power Supplies: Continuous; (9)Digital Input/Output Voltage to GND: -0.3 V, VDD + 0.3 V; (10)Thermal Resistance–Theta Junction-to-Ambient (θJA), PLCC-44: 47℃/W; (11)Package Power Dissipation: (TJ - TA)/θJA; (12)Maximum Junction Temperature TJmax: 150℃; (13)Operating Temperature Range: -40℃ to +85; (14)Storage Temperature Range: -65 to +150℃; (15)Lead Temperature (Soldering, 10 sec): +300℃.

Features

AD8600APZ-REEL features: (1)16 Independently Addressable Voltage Outputs; (2)Full-Scale Set by External Reference; (3)2 μs Settling Time; (4)Double Buffered 8-Bit Parallel Input; (5)High Speed Data Load Rate; (6)Data Readback; (7)Operates from Single +5 V; (8)Optional ±6 V Supply Extends Output Range.
