Product Summary
The AD707KRZ is a low cost, high precision op amp with state-of-the-art performance that makes it ideal for a wide range of precision applications. The offset voltage spec of less than 15 μV is the best available in a bipolar op amp, and maximum input offset current is 1.0 nA. The top grade is the first bipolar monolithic op amp to offer a maximum offset voltage drift of 0.1 μV/℃, and offset current drift and input bias current drift are both specified at 25 pA/℃ maximum. The AD707KRZ’s open-loop gain is 8 V/μV minimum over the full ±10 V output range when driving a 1 kΩ load. Maximum input voltage noise is 350 nV p-p (0.1 Hz to 10 Hz).
Parametrics
AD707KRZ absolute maximum ratings: (1)Supply Voltage: ±22 V; (2)Internal Power Dissipation: 500 mW; (3)Input Voltage: ±VS; (4)Output Short Circuit Duration: Indefinite; (5)Differential Input Voltage: +VSand –VS; (6)Storage Temperature Range (Q, H): -65℃ to +150℃; (7)Storage Temperature Range (N, R): -65℃ to +125℃; (8)Lead Temperature Range (Soldering 60 sec): +300℃.
Features
AD707KRZ features: (1)Very High DC Precision; (2)15 mV max Offset Voltage; (3)0.1 mV/8C max Offset Voltage Drift; (4)0.35 mV p-p max Voltage Noise (0.1 Hz to 10 Hz}; (5)8 V/mV min Open-Loop Gain; (6)130 dB min CMRR; (7)120 dB min PSRR; (8)1 nA max Input Bias Current; (9)AC Performance; (10)0.3 V/ms Slew Rate; (11)0.9 MHz Closed-Loop Bandwidth; (12)Dual Version: AD708; (13)Available in Tape and Reel in Accordance with; (14)EIA-481A Standard.
Diagrams
![]() |
